M Series Residential

4” Downlight

Features: Recessed, Adjustable, Wall Wash, Warm Dim, Multiple, Emergency, Decorative

Lumens: 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500​ lm (16.5W)

Color Quality: 93 CRI, 2-step SDCM

Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim, Tunable White

Beam Spread: 15° Narrow Spot, 25° Spot, 40° Flood, 60° Wide Flood, 90°+ General Ambient, Linear, Soft Focus

Dimming: 0-10V 1%, TRIAC/ELV 1%, Lutron EcoSystem 1%. DALI-2 0.1%

Input: 120/277V

Installation: New Construction, Remodel, Retrofit, Shallow Plenum, Concrete, Wood/Millwork, Flangeless Mud-In

Trims: Round, Square, Hyperbolic, Pinhole, Wall Wash, Flangeless, Decorative, Emergency, Non-Conductive Dead Front

Finish: White, Black, Bronze, Clear Diffuse, Custom

Ratings: Energy Star, Title 24 JA8, Declare Listed, Wet Location, Fire Rated, STC/IIC Sound Rated, Chicago Plenum, IC, NSF/ANSI 2 Splash Zone Safe

Warranty: 5 year; 50,000 hours

A single product family can support 98% of downlighting use cases

Write fixture schedules with ease using a single housing family that can offer a range of color temperatures, field-changeable beam angles, 120/277 voltage regulation, and 1% dimming with 0-10V or TRIAC/ELV and 0.1% Dimming with DALI-2

Keeps up with the fast-paced and ever-changing nature of projects

The system is compliant with JA8 Title 24, FCC, and UL, and is rated for installation in IC, Air-Tight, and wet locations along with being Declare Listed for Living Building Challenge and LEED projects, and is Fire, STC/IIC Sound and IK10 Impact Rated.

The modular DRD Series makes redesign a breeze.

Swapping from fixed to adjustable is as easy as changing a lightbulb – quick connects make this solution plug and play. Easily handle any design changes, even post-installation.

Features: Recessed, Adjustable, Wall Wash, Warm Dim, Multiple, Emergency, Decorative

Lumens: 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500​ lm (16.5W)

Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim, Tunable White

Trims: Round, Square, Hyperbolic, Pinhole, Wall Wash, Flangeless, Decorative, Emergency, Non-Conductive Dead Front

Ratings: Energy Star, Title 24 JA8, Declare Listed, Wet Location, Fire Rated, STC/IIC Sound Rated, Chicago Plenum, IC, NSF/ANSI 2 Splash Zone Safe
