S Series Surface Mount
Features: Edgeless Design, Non-Conductive Dead Front
Compatibility: 4″ New Construction Surface Mount Housing, Retrofit Junction Box
Lumens: 750 lm (9W), 1000 lm (12W)
Color Quality: 90+ CRI, < 3-step SDCM
Color Temperature: 2700K, 3000K, 3500K
Beam Spread: Flood
Dimming: 0-10V 1%, TRIAC/ELV 5%
Input: 120/277V 0-10V, 120V only TRIAC/ELV
Shape: 4″ Round
Finish: White
Ratings: Energy Star, Title 24 JA8, Wet Location, Closet Rated
Warranty: 5 year; 50,000 hours
Extends just 0.6 inches below the ceiling plane to minimize visual profile
Proprietary driver simplifies maintenance and dims donw to 1%
90+ CRI LED comes standard, and produces up to 1000 lumens of exceptional light
Refined appearance and remarkably thin form factor make it ideal for a huge range of applications from hotel hallways to home bathrooms to outdoor spaces
Features: Edgeless Design
Lumens: 750 lm (9W), 1000 lm (12W)
Color Temperature: 2700K, 3000K, 3500K
Beam Spread: Flood
Dimming: 0-10V 1%, TRIAC/ELV 5%
Ratings: Energy Star, Title 24 JA8, Wet Location, Closet Rated
Features: Field Changeable Optics, Integrated Driver, Warm Dim, Tunable White
Lumens: 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500 lm (14.3W)
Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim, Tunable White
Beam Spread: 15° Narrow Spot, 25° Spot, 40° Flood, 60° Wide Flood, 90°+ General Ambient, Linear, Soft Focus
Dimming: 0-10V 1%, TRIAC/ELV 1%, DALI 0.1%, Lutron EcoSystem 1%
Ratings: Energy Star, Title 24 JA8, Wet Location, NSF/ANSI 2 Splash Zone Safe
Features: Highly Customizable, Field Changeable Modules, Interchangeable Accessories, Downlight or Adjustable, IP65 Rated
Size: 4 inch, 8 inch, 12 inch
Lumens: 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500 lm (14.3W), 2000 lm (28W), 2500 lm (37W), 3000 lm (40W)
Trims: Round, Hyperbolic, Snoot, Decorative, Shade
Ratings: Energy Star, Title 24 JA8, Declare, IP65 Wet Location, NSF/ANSI 2 Splash Zone Safe, Dark Sky
Features: Edgeless Design
Lumens: 1500 lm (17W)
Color Temperature: 2700K, 3000K, 3500K
Beam Spread: Flood
Dimming: 0-10V 1%, TRIAC/ELV 5%
Ratings: Energy Star, Title 24 JA8, Wet Location, IC
Features: Precision-Crafted Aluminum, Robust Stainless-Steel Clips
Compatibility: H Series Modules and 4″ Housings
Features: Edgeless Design, Emergency Lighting
Lumens: 750 lm (9W), 1000 lm (12W)
Color Temperature: 2700K, 3000K, 3500K
Beam Spread: Flood
Dimming: 0-10V 1%
Ratings: Energy Star, Title 24 JA8, Wet Location
Features : Field Changeable Optics, Integrated Driver
Lumens : 1500 lm (20W), 2000 lm (28W), 2500 lm (37W), 3000 lm (40W)
Color Temperature : 2700K, 3000K, 3500K, 4000K
Beam Spread : 15° Narrow Spot, 25° Spot, 40° Flood, 60° Wide Flood, Linear Spread
Dimming : 0-10V 1%, Lutron EcoSystem 1%
Ratings : Energy Star, Wet Location
Features: Edgeless Design
Lumens: 1500 lm (17W)
Color Temperature: 2700K, 3000K, 3500K
Beam Spread: Flood
Dimming: 0-10V 1%, TRIAC/ELV 5%
Ratings: Energy Star, Title 24 JA8, Wet Location, IC
Features : 360° directional aim, 45° tilt, Field Changeable Optics, Integrated Driver, Warm Dim
Lumens: 750 lm (9.5W), 1000 lm (12.5W)
Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim, Tunable White
Beam Spread: 15° Narrow Spot, 25° Spot, 40° Flood, Linear, Soft Focus
Dimming: 0-10V 1%, TRIAC/ELV 1%, DALI 0.1%, Lutron EcoSystem 1%
Ratings: Energy Star, Title 24 JA8, Damp Location, NSF/ANSI Splash Zone Safe
The world’s tallest timber structure utilizes DMF’s S Series Surface Mount to combine luxury and sustainability in the pinnacle of elevated downtown living
Due to their unique usage, closets and storage spaces demand special electrical code requirements
Top five reasons why the S Series Surface Mount produces superior lighting
