Go To Configurator

2″ Downlight

X Series Module

Features: Field Changeable Optics, Integrated Driver, Warm Dim, Tunable White

Compatibility: X Series 2″ Round Housings and Downlight Trims, X Series 2″ Square Housings and Downlight Trims

Lumens: 500 lm (9.5W) – Coming soon, 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500 lm (16.5W)

Color Quality: 93 CRI, 2-step SDCM

Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim 3000-1800K, Tunable White 4000-1800K, Tunable White 6500-2700K

Beam Spread: 10° Ultra Narrow Spot – Coming Soon, 20° Narrow Spot, 30° Spot, 40° Flood, 50° Wide Flood, 50°x 30° Linear Spread

Dimming: 0-10V (1%), TRIAC/ELV (1%), DALI (0.1%)

Ratings: Energy Star, Title 24 JA8, Wet Location

Warranty: 5 year; 50,000 hours

resources

Spec Sheet
Brochure
IES Files
Revit Files
Installation Instructions
Videos
  • Quality of Light
  • Lots of Optics
  • Integrated Driver

Highest color quality, lumen output, and controls

High efficacy LEDs (93 CRI, 2-step SDCM) available in 750 lm, 1000 lm, 1250 lm or 1500 lm controlled by Triac/ELV (1%), 0-10V (1%) or DALI (0.1%).

DRDM_Overview-1
DRDM_Overview-2
DRDM_Overview-3

Put light where you want it

Field changeable optics for Spot (25°), Flood (40°), Wide Flood (60°), and Linear (40° x 40°) distributions.

Fully integrated solution eliminates remote mounted drivers

Engineered in-house specifically for DMF modules, our drivers provide smooth dimming and are completely integrated to simplify design, installation, and maintenance.

Features: Field Changeable Optics, Integrated Driver, Warm Dim, Tunable White

Lumens: 500 lm (9.5W) – Coming soon, 750 lm (9.5W), 1000 lm (12.5W), 1250 lm (14.3W), 1500 lm (16.5W)

Color Temperature: 2700K, 3000K, 3500K, 4000K, Warm Dim 3000-1800K, Tunable White 4000-1800K, Tunable White 6500-2700K

Beam Spread: 25° Spot, 40° Flood, 60° Wide Flood, Linear Spread

Dimming: 0-10V (1%), TRIAC/ELV (1%), DALI (0.1%)

Ratings: Energy Star, Title 24 JA8, Wet Location
